SNL series SNL516-613 SKF Plummer Block Bearings Housing SNL 516 SNL516-613

    Buy cheap SNL series SNL516-613 SKF Plummer Block Bearings Housing SNL 516 SNL516-613 from wholesalers

    Buy cheap SNL series SNL516-613 SKF Plummer Block Bearings Housing SNL 516 SNL516-613 from wholesalers
    • Buy cheap SNL series SNL516-613 SKF Plummer Block Bearings Housing SNL 516 SNL516-613 from wholesalers

    SNL series SNL516-613 SKF Plummer Block Bearings Housing SNL 516 SNL516-613

    Ask Lasest Price
    Brand Name : SKF/OEM
    Model Number : SNL516-613
    Certification : ISO
    Price : negotiation
    Payment Terms : T/T or western Union or PayPal
    Supply Ability : 3,000pcs per month
    Delivery Time : 3 working days after received your payment
    • Product Details
    • Company Profile

    SNL series SNL516-613 SKF Plummer Block Bearings Housing SNL 516 SNL516-613

    SNL series Plummer block housing bearing SNL516-613 SKF high quality Plummer Block Bearings Housing SNL 516 SNL516-613​


    SNL series Plummer block housing bearing SNL516-613 are typically used with self-aligning ball bearings, spherical roller bearings or CARB toroidal roller bearings fitted on straight or stepped shafts; the bearings can be mounted on adapter or withdrawal sleeves or directly on cylindrical shaft seats. These housings can also be used with other bearing types if they are within the correct Dimension Series.SNL plummer block housings set enable the incorporated bearings to achieve maximum service life with less need for maintenance. Different housing variants and seal designs are available, making the use of tailored housings virtually unnecessary and enabling costeffective bearing arrangements to be made.


    Materials of SNL series Plummer block housing bearing SNL516-613 :
    SNL plummer block housings are made of grey cast iron. For applications where the strength of grey cast iron is inadequate, dimensionally equivalent housings made of spheroidal graph-ite cast iron can be supplied. These housings are only available with four cast attachment bolt holes (series FSNLD) or without any holes in the base (series SSNLD).


    Housingdaself-aligning ball bearingspherical roller bearingCARB bearingALHH1Mass
    mmAdapter Sleevemmmmmmmmkg
    SNL516-61355.5621313 KHA231321313 K-120315177959.5

    SNL series Plummer block housing bearing SNL516-613


    housing No.Bearing No.Bearing No.
    SNL507-6061207EK2207EK
    SNL507-6071307EK2307EK
    SNL508-6071208EK2208EK
    SNL510-6081308EK2308EK
    SNL5091209EK2209EK
    SNL511-6091309EK2309EK
    SNL510-6081210EK2210EK
    SNL512-6101310EK2310K
    SNL511-6091211EK2211EK
    SNL513-6111311EK2311K
    SNL512-6101212EK2212EK
    SNL515-6121312EK2312K
    SNL513-6111213EK2213EK
    SNL516-6131313EK2313K
    SNL515-6121215K2215EK
    SNL518-6151315K2315K
    SNL516-6131216K2216EK
    SNL519-6161316K2316K
    SNL 5171217K2217K
    SNL520-6171317K2317K
    SNL518-6151218K2218K
    SNL519-6161219K2219K
    SNL522-6191319K2319K
    SNL52622226EK23226CCK/W33
    SNL52822228CCK/W3323228CCK/W33
    SNL53222232CCK/W3323232CCK/W33
    SNL2051205E2205E
    SNL206-3051305E2305
