Large SNL series Plummer block housing SNL3144 SNL 3144 bearing block split plummer block housings SNL3144

SNL plummer block housings in the 30, 31 and 32 series are also referred to as “Large SNL plummer block housings”. These plummer block housings enable the bearings to achieve maximum bearing service life with less need for maintenance. This supports user efforts to further reduce maintenance costs. Among other enhancements, SNL housings are designed for easy alignment and handling during installation. Another benefit is the choice of oil or grease lubrication for the bearings housed in SNL plummer blocks. A range of seals for oil lubrication and difficult environments provide trouble-free operation.

SNL plummer block housings are made of grey cast iron. For applications where the strength of grey cast iron is inadequate, dimensionally equivalent housings made of spheroidal graph-ite cast iron can be supplied. These housings are only available with four cast attachment bolt holes (series FSNLD) or without any holes in the base (series SSNLD).

Plummer block housing SNL3144 SNL 3144 bearing block types Specification :

Split plummer block housing bearings SNL500 series model list :

Bearing types :

• Self-aligning ball bearings
• Spherical roller bearings
• CARB toroidal roller bearings

Customer demands :
• Robust design
• No breakdowns
• Extremely effective seals
• Long maintenance intervals
• Condition monitoring facilities
• Fast and easy mounting and dismounting

Mounting aid :
To simplify mounting and make alignment more accurate, cast indications in the end faces of the housing base indicate the housing bore axis and the vertical axis.

Heat conduction :
The extra ribs in the housing base provide additional surface area between the base and base plate to improve heat flow away from the bearing.

Lubrication :
SNL plummer block housings with standard seals are designed for grease lubrication. For oil lubrication, modified SNL housings are available. These housings are supplied only together with the seals specially developed for oil lubrication.

  Established in 1989, Wuxi Guangqiang Bearing Trade Co.,Ltd works hard in researching and manufacturing high quality bearings and rely on it's advantages of strong technologies, advanced equipment, professional technical team, quality production and reasonable prices has gain a broad recognitiongain and won the widely support and trust by customers in bearing fields.

  For decades, the company established and completed the quality management system of scientific standardization in line with international standards. In 2005 they won the title of Chinese famous brand ranging from tapered roller bearings, cylindrical roller bearings, spherical roller bearings, thrust ball bearing, angular contact ball bearings, deep groove ball bearings and various non-standard bearings etc.

  Our products are widely used in auto industries, construction machinery industries, electric power industries, pharmaceutical field, mining machinery, printing industries, highway engineering machinery, steel industires, textile machine industries and so on.

  Capable of solving all your bearing issues with its first-class professional advisers and skilled engineers, Wuxi Guangqiang Bearing Trade Co.,Ltd embrace any inquiry, negotiation, cooperation from new and old friends at any time.
