KB100ARO Kaydon Thin Section Bearing for Robert , Slim Section
Bearings
Thin section bearings have high precision, are very quiet and have
high load carrying capacity . These ball bearings are available in
three different designs and have an extremely small, predominantly
square cross-section. Within each series, the cross-section remains
constant even for larger shaft diameters and housing bores.
Details of thin section bearing
The bearings are therefore also described as Constant Section (CS).
This special feature distinguishes thin section bearings from
conventional bearings as standardised in ISO series.
It is therefore possible to select a larger cross-section and thus
use a bearing with
higher load carrying capacity without the need to change the shaft
diameter as well.
Thin section bearings allow designs to be achieved that are
extremely light and require little space.
Thin section bearings are available as deep groove ball bearings
(C), four point contact
bearings (X) and angular contact ball bearings (E). Each of these
designs is available in
various series. The series correspond to the crosssection sizes.
Model of Thin section bearing
Thin section bearing | Structure | Type A | Type C | Type X |
Angular Contact Ball | Radial contact Ball | Four Point Contact Ball |
| (Deep Groove Ball) | |
REALI-SLIM | Open Type bearings | KAA | Type A-KAA | Type C-KAA | Type X-KAA |
KA | Type A-KA | Type C-KA | Type X-KA |
KB | Type A-KB | Type C-KB | Type X-KB |
KC | Type A-KC | Type C-KC | Type X-KC |
KD | Type A-KD | Type C-KD | Type X-KD |
KF | Type A-KF | Type C-KF | Type X-KF |
KG | Type A-KG | Type C-KG | Type X-KG |
Sealed Bearings | JHA | / | Type C-JHA | Type X-JHA |
JA | / | Type C-JA | Type X-JA |
JB | / | Type C-JB | Type X-JB |
JU | / | Type C-JU | Type X-JU |
JG | / | Type C-JG | Type X-JG |
Stainless Steel | SAA | Type A-SAA | Type C-SAA | Type X-SAA |
SA | Type A-SA | Type C-SA | Type X-SA |
SB | Type A-SB | Type C-SB | Type X-SB |
Metric Series | 8mm | Type A-8mm | Type C-8mm | Type X-8mm |
13mm | Type A-13mm | Type C-13mm | Type X-13mm |
20mm | Type A-20mm | Type C-20mm | Type X-20mm |
Ultra-Slim | Ultra-Slim | Type A-Ultra-Slim | Type C-Ultra-Slim | Type X-Ultra-Slim |
KB020ARO US KAYDON high-precision thin wall bearing
KB025ARO US KAYDON high-precision thin wall bearing
KB030ARO US KAYDON high-precision thin wall bearing
KB035ARO US KAYDON high-precision thin wall bearing
KB040ARO US KAYDON high-precision thin wall bearing
KB042ARO US KAYDON high-precision thin wall bearing
KB045ARO US KAYDON high-precision thin wall bearing
KB047ARO US KAYDON high-precision thin wall bearing
KB050ARO US KAYDON high-precision thin wall bearing
KB055ARO US KAYDON high-precision thin wall bearing
KB060ARO US KAYDON high-precision thin wall bearing
Pictures of thin section bearing
