    Steel Cage 51308 Thrust Ball Bearing Long Durability Single Direction 40x78x26mm

    Ask Lasest Price
    Brand Name : Optional
    Model Number : 51308
    Certification : ISO9001
    Payment Terms : T/T, Western Union,Paypal,
    Delivery Time : 2 ~ 5 working days
    • Product Details
    • Company Profile

    Steel Cage 51308 Thrust Ball Bearing Long Durability Single Direction 40x78x26mm

    Steel Cage 51308 Thrust Ball Bearing Long Durability Single Direction 40x78x26mm


    BearingModel51308
    MaterialBearing Steel GCr15 ; Others
    TypeThrust Deep Groove Ball Bearing
    d (mm)40
    D (mm)78
    B (mm)26
    Mass (KG)0.54
    Precision

    P0, P6, P5 ,P4 ,P2


    We currently have 2850.pcs of 51308 Single Direction Thrust Deep Groove Ball Bearing In Stock.If you are in need of 51308 Bearing ,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.


    For more details of 51308 ,please feel free to contact me by WhatsApp or SKYPE or E-mail.


    Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the "

    Contact Now "button for Price & other Information.


    Bearing Model

    d

    (mm)

    D

    (mm)

    B

    (mm)

    Bearing Model

    d

    (mm)

    D

    (mm)

    B

    (mm)

    Bearing Model

    d

    (mm)

    D

    (mm)

    B

    (mm)

    51100102495120010261151405256024
    51101122695120112281151406307028
    51102152895120215321251407358032
    51103173095120317351251408409036
    5110420351051204204014514094510039
    5110525421151205254715514105011043
    5110630471151206305216514115512048
    511073552125120735621851412-MP6013051
    511084060135120840681951413-MP6514056
    511094565145120945732051414-MP7015060
    511105070145121050782251415-MP7516065
    511115578165121155902551416-MP8017068
    511126085175121260952651417-MP8518072
    5111365901851213651002751418-MP9019077
    5111470951851214701052751420-MP10021085
    51115751001951215751102751422-MP11023095
    51116801051951216801152851424-MP120250102
    51117851101951217851253151305255218
    51118901202251218901353551306306021
    5112010013525512201001503851307356824
    5112211014525512221101603851308407826
    5112412015525512241201703951309458528
    5112613017030512261301904551310509531
    51128140180315122814020046513115510535
    51130-MP1501903151230-MP15021550513126011035
    51132-MP1602003151232-MP16022551513136511536
    51134-MP1702153451234-MP17024055513147012540
    51136-MP1802253451236-MP18025056513157513544
    51138-MP1902403751238-MP19027062513168014044
    51140-MP2002503751240-MP20028062513178515049
    51144-MP2202703751244-MP22030063513189015550
    51148-MP2403004551248-MP240340785132010017055
    51152-MP2603204551252-MP2603607951322-MP11019063
    51156-MP2803505351256-MP2803808051324-MP12021070
    51160-MP3003806251260-MP3004209551326-MP13022575
    51164-MP3204006351264-MP3204409551328-MP14024080
    51168-MP3404206451268-MP3404609651330-MP15025080
    51172-MP3604406551272-MP36050011051332-MP16027087

    SuffixDescription
    MPSolid brass window cage, ball-guided
    P5Higher accuracy totolerance class P5
    P6Higher accuracy totolerance class P6

    Introduction


    Axial deep groove ball bearings comprise shaft locating washers, housing locating washers and ball and cage assemblies. The bearings are not self-retaining; the ball and cage assembly and bearing washers can therefore be fitted separately.


    Single direction axial deep groove ball bearings can support axial forces in one direction.Bearings of series 511, 512, 513 and 514 have a flat housing locating washer. They do not permit angular misalignment or skewing between the shaft and housing.


    Operating Temperature

    Axial deep groove ball bearings can be used at operating temperatures from –30 °C to +150 °C, restricted by the lubricant.

    51308 Thrust Ball Bearing

    51308 Thrust Ball Bearing51308 Thrust Ball Bearing
