High Accuracy Thrust Ball Bearing 51311 , Thrust Washer Bearing 55 X 105 X 35MM

Ask Lasest Price
Brand Name :	Optional
Model Number :	51311
Certification :	ISO9001
Payment Terms :	T/T, Western Union,Paypal,
Delivery Time :	2 ~ 5 working days

Add to Cart

Product Details
Company Profile

High Accuracy Thrust Ball Bearing 51311 , Thrust Washer Bearing 55 X 105 X 35MM

High Accuracy Thrust Ball Bearing 51311 , Thrust Washer Bearing 55 X 105 X 35MM

BearingModel	51311
Material	Bearing Steel GCr15 ; Others
Type	Thrust Deep Groove Ball Bearing
d (mm)	55
D (mm)	105
B (mm)	35
Mass (KG)	1.30
Precision	P0, P6, P5 ,P4 ,P2

We currently have 1900.pcs of 51311 Single Direction Thrust Deep Groove Ball Bearing In Stock.If you are in need of 51311 Bearing ,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.

For more details of 51311 ,please feel free to contact me by WhatsApp or SKYPE or E-mail.

Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the " Contact Now "button for Price & other Information.

Bearing Model	d (mm)	D (mm)	B (mm)	Bearing Model	d (mm)	D (mm)	B (mm)	Bearing Model	d (mm)	D (mm)	B (mm)
51100	10	24	9	51200	10	26	11	51405	25	60	24
51101	12	26	9	51201	12	28	11	51406	30	70	28
51102	15	28	9	51202	15	32	12	51407	35	80	32
51103	17	30	9	51203	17	35	12	51408	40	90	36
51104	20	35	10	51204	20	40	14	51409	45	100	39
51105	25	42	11	51205	25	47	15	51410	50	110	43
51106	30	47	11	51206	30	52	16	51411	55	120	48
51107	35	52	12	51207	35	62	18	51412-MP	60	130	51
51108	40	60	13	51208	40	68	19	51413-MP	65	140	56
51109	45	65	14	51209	45	73	20	51414-MP	70	150	60
51110	50	70	14	51210	50	78	22	51415-MP	75	160	65
51111	55	78	16	51211	55	90	25	51416-MP	80	170	68
51112	60	85	17	51212	60	95	26	51417-MP	85	180	72
51113	65	90	18	51213	65	100	27	51418-MP	90	190	77
51114	70	95	18	51214	70	105	27	51420-MP	100	210	85
51115	75	100	19	51215	75	110	27	51422-MP	110	230	95
51116	80	105	19	51216	80	115	28	51424-MP	120	250	102
51117	85	110	19	51217	85	125	31	51305	25	52	18
51118	90	120	22	51218	90	135	35	51306	30	60	21
51120	100	135	25	51220	100	150	38	51307	35	68	24
51122	110	145	25	51222	110	160	38	51308	40	78	26
51124	120	155	25	51224	120	170	39	51309	45	85	28
51126	130	170	30	51226	130	190	45	51310	50	95	31
51128	140	180	31	51228	140	200	46	51311	55	105	35
51130-MP	150	190	31	51230-MP	150	215	50	51312	60	110	35
51132-MP	160	200	31	51232-MP	160	225	51	51313	65	115	36
51134-MP	170	215	34	51234-MP	170	240	55	51314	70	125	40
51136-MP	180	225	34	51236-MP	180	250	56	51315	75	135	44
51138-MP	190	240	37	51238-MP	190	270	62	51316	80	140	44
51140-MP	200	250	37	51240-MP	200	280	62	51317	85	150	49
51144-MP	220	270	37	51244-MP	220	300	63	51318	90	155	50
51148-MP	240	300	45	51248-MP	240	340	78	51320	100	170	55
51152-MP	260	320	45	51252-MP	260	360	79	51322-MP	110	190	63
51156-MP	280	350	53	51256-MP	280	380	80	51324-MP	120	210	70
51160-MP	300	380	62	51260-MP	300	420	95	51326-MP	130	225	75
51164-MP	320	400	63	51264-MP	320	440	95	51328-MP	140	240	80
51168-MP	340	420	64	51268-MP	340	460	96	51330-MP	150	250	80
51172-MP	360	440	65	51272-MP	360	500	110	51332-MP	160	270	87

Suffix	Description
MP	Solid brass window cage, ball-guided
P5	Higher accuracy totolerance class P5
P6	Higher accuracy totolerance class P6

Introduction

Axial deep groove ball bearings comprise shaft locating washers, housing locating washers and ball and cage assemblies. The bearings are not self-retaining; the ball and cage assembly and bearing washers can therefore be fitted separately.

Single direction axial deep groove ball bearings can support axial forces in one direction.Bearings of series 511, 512, 513 and 514 have a flat housing locating washer. They do not permit angular misalignment or skewing between the shaft and housing.

Operating Temperature

Axial deep groove ball bearings can be used at operating temperatures from –30 °C to +150 °C, restricted by the lubricant.
