    Original High Speed Thrust Bearing Low Friction 53238U 53238 51238

    Ask Lasest Price
    Brand Name : NACHI
    Model Number : 51310
    Certification : ISO9001
    Payment Terms : T/T, Western Union,Paypal,
    Delivery Time : 2 ~ 5 working days
    • Product Details
    • Company Profile

    Original High Speed Thrust Bearing Low Friction 53238U 53238 51238

    Original High Speed Thrust Bearing Low Friction 53238U 53238 51238


    Product Description

    Overview of NACHI Thrust Ball Bearings

    Thrust ball bearings are designed to handle axial loads only.

    Thrust ball bearings consist of ball, retainer and both shaft and housing washers which contain grooves for the ball.

    The double Direction Thrust ball bearings can support bi-directional loads.

    The bearings with spherical housing washer can prevent static misalignment.

    Thrust ball bearings consist of ball, retainer, both shaft and housing washers which contain grooves for the balls, and can be subject to axial load only.

    Since introduction of polyamide cages the level of noise substantially improved.


    Attention

    The design of Thrust Ball Bearing may not be subjected to any radial load.

    Thrust Ball Bearings are not suitable for high-speed rotation since lubricant is expelled by centrifugal force.

    When used on a horizontal shaft, a minimum axial load must be applied.

    Care must be taken in handling to prevent damage to the separable rings and ball assembly.

    Technical Parameters of NACHI Thrust Ball Bearing 53238U 53238 51238

    NACHI Thrust Ball Bearing 53238U 53238 51238

    Brand Name

    NACHI

    Structure

    Thrust Ball

    Size(d*D*T)

    190*270*62mm

    Weight

    14kg

    ClearanceC0,C2,C3,C4,C5

    Precision Rating

    ABEC1,ABEC3,ABEC5,ABEC7,ABEC9

    Vibration

    V1,V2,V3,V4

    Noise Level

    Z1,Z2,Z3,Z4

    Packing

    According to your requirements.

    Cage

    Steel / Brass / Nylon

    Application

    1. Ball Thrust Bearings should use close to the radial bearing, in order to prevent the effect of shafts deflection.

    2. When using big size ball bearings on a horizontal shaft, preload should be implemented to prevent the clearance between housing washer and balls.

    3. Under the inevitable circumstances of shaft deflection and misalignment, aligning seat washer should be applied.
