    3804-B-TVH Precision Angular Contact Bearings 20x32x10mm High Speed Ball Bearing

    Ask Lasest Price
    Brand Name : Optional
    Model Number : 3804-B 3804-B-TVH
    Certification : ISO9001
    Payment Terms : T/T, Western Union,Paypal,
    Delivery Time : 2 ~ 5 working days
    • Product Details
    • Company Profile

    3804-B-TVH Precision Angular Contact Bearings 20x32x10mm High Speed Ball Bearing

    3804-B-TVH Precision Angular Contact Bearings , 20x32x10mm High Speed Ball Bearing


    BearingModel3804-B 3804-B-TVH
    Contact Angle25°
    TypeDouble Row Angular Contact Ball Bearing
    d (mm)20
    D (mm)32
    B (mm)10
    Mass (KG)0.02
    Precision

    P6, P5 ,P4 ,P2


    We currently have 650.pcs of 3804-B-TVH Double Row Angular Contact Ball Bearing In Stock.If you are in need of 3804-B-TVH Ball Bearing ,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.


    For more details of 3804-B-TVH ,please feel free to contact me by WhatsApp or SKYPE or E-mail.


    Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the "

    Contact Now "button for Price & other Information.


    Bearing

    Model

    d

    (mm)

    D

    (mm)

    B

    (mm)

    3800-B-TVH10197
    3801-B-TVH12217
    3802-B-TVH15247
    3803-B-TVH17267
    3804-B-TVH203210
    3805-B-TVH253710
    3806-B-TVH304210
    3807-B-TVH354710
    3808-B-TVH405210
    3809-B-TVH455810
    3810-B-TVH506512
    3811-B-TVH557213
    3812-B-TVH607814
    3814-B-TVH709015
    3816-B-TVH8010015

    Bearing

    Model

    d

    (mm)

    D

    (mm)

    B

    (mm)

    3302-BD-TVH154219
    3303-BD-TVH174722,2
    3304-BD205222,2
    3304-BD-TVH205222,2
    3305-BD256225,4
    3305-BD-TVH256225,4
    3306-BD307230,2
    3306-BD-TVH307230,2
    3307-BD358034,9
    3307-BD-TVH358034,9
    3308-BD409036,5
    3308-BD-TVH409036,5
    3309-BD4510039,7
    3309-BD-TVH4510039,7
    3310-BD5011044,4
    3310-BD-TVH5011044,4
    3311-BD5512049,2
    3311-BD-TVH5512049,2

    SuffixDescription
    BModified internal construction,contact angle α = 25°, without filling slot
    C2Axial internal clearance C2
    C3Axial internal clearance C3
    DAInner ring split
    MSolid brass cage, ball-guided
    MASolid brass cage,guidance on outer ring
    TVHSolid polyamide snap cage,ball-guided
    2RSRLip seals on both sides
    2ZGap seals on both sides

    Introduction


    Double row angular contact ball bearings are units with solid inner and outer rings and ball and cage assemblies with polyamide, sheet steel or brass cages. Their construction is similar to a pair of single row angular contact ball bearings in an O arrangement but they are narrower to a certain extent. They differ in the size of the contact angle and the design of the bearing rings.


    Sealing

    Series 38..-B, 30..-B, 32..-B and 33..-B with the suffix 2RSR are sealed by lip seals on both sides. Contact seals are suitable for giving protection against dust, contamination and damp atmospheres.
    Series with the suffix 2Z have gap seals on both sides.


    Lubrication

    Sealed bearings are greased with a high quality grease and are lubricated for life.


    Operating temperature


    Open bearings are suitable for operating temperatures from –30 °C to +150 °C.
