HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

Ask Lasest Price
Brand Name :	NSK OR OEM
Model Number :	HCB7026-C-2RSD-T-P4S
Certification :	ISO9001
Price :	USD0.1-1000/PC
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	100000pcs/Week
Delivery Time :	3-5 work days

Add to Cart

Product Details
Company Profile

HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

The Brief Description of Spindle Bearings:

Splindle bearings are single row angular contact ball bearings comprising solid inner and outer rings and ball and cage assemblies with solid window cages. They cannot be dismantled. The bearings are available in open and sealed versions.

Spindle bearings have restricted tolerances. They are particularly suitable for bearing arrangements with very high requirements for guidance accuracy and speed capacity. They have proved highly suitable for the bearing arrangements of spindles in machine tools.

pecifications of spindle bearings HCB7026-C-2RSD-T-P4S:

HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

Types of the spindle bearings:

B spindle bearings:

♣Classical spindle bearing

♣With large balls

♣Contact angle 15° and 25°

♣High load carrying capacity and high rigidity

♣For moderate speed level.

H spindle bearings(high speed design)

♦With small balls

♦Contact angle 15° and 25°

♦Suitable for very high speeds due to internal design with optimised friction and very low centrifugal forces on the rolling elements

♦High rigidity at high speeds

♦Particularly suitable for very high speed spindle and grinding spindles.

RS spindle bearings

♥New design

♥Wieh large balls

♥Contact angle 20°

♥Suitable for high to very high speeds due to bearing internal design with optimised friction

♥Kinematic insensitivity to tilting

♥High load carrying capacity especially under combined axial radial load

♥Particularly suitable for high speed milling spindles and motor spindles.

The structure for spindle bearings:

HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

Marking of open spindle bearings:

HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

Marking of sealed spindle bearings:

HCB7026-C-2RSD-T-P4S High Speed Spindle Bearing 130x200x33 mm Angular Contact Ball Bearings

Spindle Bearings Catalogs:

Bearing No.	d(mm)	D(mm)	B(mm)
HCB7000-C-T-P4S	10	26	8
HCB7001-C-T-P4S	12	28	8
HCB7002-C-T-P4S	15	32	9
HCB7003-C-T-P4S	17	35	10
HCB7004-C-T-P4S	20	42	12
HCB7005-C-T-P4S	25	47	12
HCB7006-C-T-P4S	30	55	13
HCB7007-C-T-P4S	35	62	14
HCB7008-C-T-P4S	40	68	15
HCB7009-C-T-P4S	45	75	16
HCB7010-C-T-P4S	50	80	16
HCB7011-C-T-P4S	55	90	18
HCB7012-C-T-P4S	60	95	18
HCB7013-C-T-P4S	65	100	18
HCB7014-C-T-P4S	70	110	20
HCB7015-C-T-P4S	75	115	20
HCB7016-C-T-P4S	80	125	22
HCB7017-C-T-P4S	85	130	22
HCB7018-C-T-P4S	90	140	24
HCB7019-C-T-P4S	95	145	24
HCB7020-C-T-P4S	100	150	24
HCB7021-C-T-P4S	105	160	26
HCB7022-C-T-P4S	110	170	28
HCB7024-C-T-P4S	120	180	28
HCB7026-C-T-P4S	130	200	33
HCB7028-C-T-P4S	140	210	33
HCB7030-C-T-P4S	150	225	35
HCB7032-C-T-P4S	160	240	38
HCB7034-C-T-P4S	170	260	42
HCB7036-C-T-P4S	180	280	46
HCB7038-C-T-P4S	190	290	46
HCB7040-C-T-P4S	200	310	51
HCB7000-E-T-P4S	10	26	8
HCB7001-E-T-P4S	12	28	8
HCB7002-E-T-P4S	15	32	9
HCB7003-E-T-P4S	17	35	10
HCB7004-E-T-P4S	20	42	12
HCB7005-E-T-P4S	25	47	12
HCB7006-E-T-P4S	30	55	13
HCB7007-E-T-P4S	35	62	14
HCB7008-E-T-P4S	40	68	15
HCB7009-E-T-P4S	45	75	16
HCB7010-E-T-P4S	50	80	16
HCB7011-E-T-P4S	55	90	18
HCB7012-E-T-P4S	60	95	18
HCB7013-E-T-P4S	65	100	18
HCB7014-E-T-P4S	70	110	20
