The Brief Description of HG series linear guideways Bearings:
HG series linear guideways are designed with load capacity and
rigidity higher than other similar products with circular-arc
groove and structure optimization. It features equal load ratings
in the radial,reverse radial and lateral directions, and
self-aligning to absorb installation-error. Thus,HIWIN HG series
linear guideways can achieve a long life with high speed, high
accuracy and smooth linear motion.
Construction of HG series hiwin linear guideways:
Dimensions for HIWIN HG series linear guideways(HGH-CA/HGH-HA):
HIWIN HG series linear guideways Models:
| HGH-CA/HGH-HA | HGH15CA | HGW- CA/HGW-HA | HGW15CA | HGW-CC/HGW-HC | HGW15CC |
| HGH20CA | HGW20CA | HGW20CC |
| HGH20HA | HGW20HA | HGW20HC |
| HGH25CA | HGW25CA | HGW25CC |
| HGH25HA | HGW25HA | HGW25HC |
| HGH30CA | HGW30CA | HGW30CC |
| HGH30HA | HGW30HA | HGW30HC |
| HGH35CA | HGW35CA | HGW35CC |
| HGH35HA | HGW35HA | HGW35HC |
| HGH45CA | HGW45CA | HGW45CC |
| HGH45HA | HGW45HA | HGW45HC |
| HGH55CA | HGW55CA | HGW55CC |
| HGH55HA | HGW55HA | HGW55HC |
| HGH65CA | HGW65CA | HGW65CC |
| HGH65HA | HGW65HA | HGW65HC |
| HGL-CA/HGL-HA | HGL15CA | HGW-CB/HGW-HB | HGW15CB | HGR-T | HGR15T |
| HGL25CA | HGW20CB | HGR20T |
| HGL25HA | HGW20HB | HGR25T |
| HGL30CA | HGW25CB | HGR30T |
| HGL30HA | HGW25HB | HGR35T |
| HGL35CA | HGW30CB | HGR45T |
| HGL35HA | HGW30HB | HGR55T |
| HGL45CA | HGW35CB | HGR65T |
| HGL45HA | HGW35HB | |
| HGL55CA | HGW45CB | |
| HGL55HA | HGW45HB | |
When you don't know how to choose hiwin linear guideways:
HG series--Grinding,milling,and drilling machine,lathe,machine
center
EG series--Automatic equipment,high speed transfer
device,semiconductor equipment,wood cutting machine,precision
measure equipment
QE/QH series--precision measure equipment,semiconductor
equipment,antomatic equipment, laser marking machine,can be widely
applied in high-tech industry required high speed,low noise,low
dust generation.
WE series--Automatic device,transportation device,precision measure
equipment,semiconductor equipment, blow moulding machine, single
axis robot-robotics.
MGN/MGW series--Miniature device,semiconductor equipment,medical
equipment
RG series--CNC machining centers,heavy duty cutting machines,CNC
grinding machines,injection molding machines,electric discharge
machines,wire cutting machines,plano millers
Our package about HIWIN linear guideways:
