    20mm Shaft Diameter Alumunum Alloy Linear Block SBR20UU Linear Motion Slide Units

    Ask Lasest Price
    Brand Name : GQZ
    Model Number : SBR20UU
    Certification : ISO9001:2008
    Price : negotiation
    Payment Terms : T/T or western Union or PayPal
    Supply Ability : 3,000pcs per month
    Delivery Time : 3 working days after received your payment
    • Product Details
    • Company Profile

    20mm Shaft Diameter Alumunum Alloy Linear Block SBR20UU Linear Motion Slide Units


    20mm Shaft Diameter Alumunum Alloy Linear Block SBR20UU Linear Motion Slide Units


    1. Specification:


    SBR/TBR Cylindrical linear guide rail is composed of a rail support, a shaft (rail), and number of blocks. They are provided as a unit or as respective components as well. All components are standardized to be fully interchangeable.


    Support Rail (SBS/TBS)

    Support Rail provides maximum rigidity and stiffness to the shaft throughout the whole stroke, and ensure the performance of the unit.


    Case (SBR/TBR )

    Effective for high load or long stroke application with maximum rigidity and excelent motion in combination with Open type Linear Bushing. Moreover , preload can be applied on SBR/TBR/SMD series for high precision performance.


    Support Rail Unit (SBR-S/TBR-S)

    SBR-S and TBR-S type are optimum guide units for high precision and deflection free sliding system with smooth motion and maximum rigidity, and less cost and time.


    2. Feature:

    (1) Good quality

    (2) Competitive price

    (3) Quick delivery
    (4) Long-term quality guarantee


    3. Bearing Picture:


    4. We also supply following SBR bearings:

    ModelDimension(mm)Slide bush
    hEWLFH1θBCSL1Tno.
    SBR10UU1518363224680°2520M5107LM10UUOP
    SBR13UU1720403927.68.580°2828M5108LM13UUOP
    SBR16UU2022.54545331080°3230M5129LM16UUOP
    SBR20UU23244850391060°3535M61211LM20UUOP
    SBR25UU273060654711.550°4040M61214LM25UUOP
    SBR30UU33357070561450°5050M81815LM30UUOP
    SBR35UU37408080631650°5555M81818LM35UUOP
    SBR40UU42459090721950°6565M102020LM40UUOP
    SBR50UU5360120110922350°9480M102025LM50UUOP
    SBR16LUU2022.54585331080°3260M5129LM16LUUOP
    SBR20LUU23244896391060°3570M61211LM20LUUOP
    SBR25LUU2730601304711.550°40100M61214LM25LUUOP
    SBR30LUU333570140561450°50110M81815LM30LUUOP
    SBR40LUU424590175721950°65180M102020LM40LUUOP

    If you have any inquiry,please contact us!
